  4. Combo Statie de incarcare ultra rapida cu monetizare iHunt EV DC 120KW V4, 2 x CCS2 + Baterie Stocare 400KWh - Integrare iHuntEV

iHunt Combo Statie de incarcare ultra rapida cu monetizare iHunt EV DC 120KW V4, 2 x CCS2 + Baterie Stocare 400KWh - Integrare iHuntEV

iHunt
-3%
699.900,00 Lei 677.900,00 Lei
In stock
Stock limit
Add to cart
Product Code: ihunt-evdc-120kw-battery-400kwh Do you need help? 021 9951
Add to wishlist Request information Quick Order
  • Description
  • Reviews (0)

Preț valabil cu integrare în iHunt EV






1. Încărcare rapidă 120kW + stocare 400kWh

2. Funcționează cu energie solară (panouri până la 50kW)

3. Autonomie și eficiență maximă, fără dependență de rețea


SPECIFICAȚII STAȚIA DE ÎNCĂRCARE - iHunt EV DC 120KW


S. NO. Parameters Requirements
General Requirements
1 Charger Capacity 120kW

Input Requirements
2 AC Supply System Three-Phase, 5 Wire AC system
3 Nominal Input voltage 380V±15%
4 Input frequency 45-65Hz
Environmental Requirements
5 Ambient Temperature Range -25 to 55°C
6 Ambient Humidity 5 to 95%
7 Storage temperature -40 to 70°C
8 Environmental Condition Outdoor use
Mechanical Requirements
9 Mechanical Stability As per IEC 61851-1 Section 11.11.2
10 IP Ratings IP 55
11 Cooling Forced air cooled
Output Requirements
12 Number of outputs 2
13 Type of each output DC200-1000V
14 Output Current Max. 300 Amp
15 Output Connector Compatibility IEC 62196, IEC 61851
16 Converter Efficiency ≥95% at nominal output power
17 Power Factor ≥0.99 (Full load)
User Interface & Display Requirements
18 Emergency stop switch Support
19 Display 12.1 inch color touch screen
20 User Authentication QR Code/RFID Card /Password Login
21 Metering Information Consumption Units
Communication Requirements
22 Communication between EVSE and Central Server Open Charge Point Protocol (OCPP) 1.6 protocol
23 Metering Grid responsive metering as per units' consumption of each vehicle
24 Interface between charger and CMS Ethernet/3G/4G/WIFI
Protection & Safety Requirements
25 Safety Parameters Over current, under voltage, residual current, surge protection, leakage protection, short circuit, over temperature, etc.
See more Product compliance information
